Name: | GKDMZ Series Dual Pulse Power Supply For Irregular Gold And Silver Jewelry Plating | Input Voltage: | 3xAC220V/380V±10%,50/60Hz |
---|---|---|---|
Output Voltage: | 0- 250vdc, Customized; | Output Current: | 0 - No Upper Limit (manual 64000A Maximum) |
Insulation Resistance: | Input-output / Input-shell / Output-shell: ≥ 5m Ω | Cooling Mode: | Air Cooled Or Water Cooled |
Highlight: | Electroplating Rectifier For Silver Plating,Dual Pulse Power Supply Electroplating Rectifier,Dual Pulse Power Supply silver plating rectifier |
GKDMZ Series Dual Pulse Power Supply For Irregular Gold And Silver Jewelry Plating
Application
For coloring aluminum
Used in copper plating, blind hole, hole filling and other copper processes of PCB
It is used in irregular gold and silver jewelry plating and other irregular
shape plating parts, etc
Features:
1. The distortion of pulse waveform is weak, which is similar to the theoretical waveform
2. DC mode and pulse mode, free choice
3. Constant current and voltage operation mode, free switching
4. The output waveform can be customized instead of selective output, and the
automatic control can work in unlimited different phases
5. Equipped with RS232 & RS485 interface;
6. 4-20mA, 0-5V, 0-10V analog(optional)
7. PROFIBUS, DeviceNet, modbus(optional)
8. Built in ampere hour meter function;
9. With over temperature, over voltage, under voltage, overload, short circuit protection function;
10. Sealing structure design, with the use of acid and alkali proof waterproof function- three
anti paint, make the product more durable;
Technical parameters:
Line voltage |
3xAC220V±10%,50/60Hz 3xAC380V±10%,50/60Hz Other voltages can be customized as required |
Output Voltage | 0- 250vdc, customized; |
Positive Pulse Current | 0 - no upper limit (manual 64000A maximum) |
Negative pulse current | 0 - no upper limit (manual 64000A maximum) |
Pulse width | 1-3000ms |
Pulse step | 1ms or 0.1ms |
Accuracy | ≤1% |
Output waveform | Custom (non selective output) |
Insulation resistance | Input-output / input-shell / output-shell: ≥ 5m Ω |
Rated efficiency | 80% type |
Cooling mode | Air cooled or water cooled |
Load capacity | No fault during 72 hours of full load operation |
RoHS compliance | conformity with EU Directive 2011/65/EU |
Safety standards | conformity with EU 2006/95/EC,2004/108/EC |
Degree of Protection | Air cooling IP33, water cooling IP43 or 66 |
FAQ
1. How can I get an offer?
You can send your drawing with technology requirements and mark your purchase quantity of the product you need.It is much better if you could offer the usage information about products.
We will comfirm the most suitable material and quote our best price to you in 24 hours.
2. Can you accept OEM & ODM?
Yes,we can produce the products according to your demand and drawing.
3. What is your production lead-time for order?
Generally it takes 15-25 days for production.
4. What are your payment terms?
In generally,we quote EXW price+shipping cost,payment 50% deposit by T/T in advance,50% balance paid before shipment.
If the account is small ,so you can pay via Western Union.
Products Show
1. Automatic Barrel plating production line
2. Automatic rack plating production line
Application: large-scale surface treatment of metal parts such as machinery, automobiles, military industry,electronics and ABS
non-metal parts, suitable for zinc plating, chrome plating, nickel plating, copper plating and other processes.
3. Precision roller
Application range:Small batch surface treatment of metal parts such as precision military electronics, suitable for nickel plating,
gold plating, tin plating, copper plating and other processes
Project display
![]() |
![]() |
![]() |
![]() |
Packing & Shipping
In our company,various packing methods are adopted according to different product features,such as carton boxes,wooden case etc.For electroplating plant equipment ,we can discuss it together and choose the most suitable one.
As for shipment,different ways have their own advantage and disadvantage:
By sea: the cheapest,suitable for large amounts,but take more time
By Air: faster, more convenient, much more expensive
By Express: more flexiable, door to door, a little bit expensive
