2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes

2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes
2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes
2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes

Large Image :  2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes

Product Details:
Place of Origin: China
Brand Name: surplus
Certification: ISO9001
Model Number: IH-04
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 7-15 working days
Payment Terms: T/T, Western Union
Supply Ability: 100 pcs per month

2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes

Description
Product Name: 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes Power Source: Electric
Voltage: 120-600V Certification: ISO9001 CE
Warranty: 1 Year Material: PFA
Application: Semiconductor Wet Processes,Sterilization/Cleaning,Solar/Photovoltaic Wafer Cleaning
High Light:

2KW Inline Chemical Heater

,

Ultrapure PFA Inline Chemical Heater

,

Semiconductor PTFE Immersion Heater

2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes

PFA Inline Chemical Heater

2KW 3.5KW Ultrapure PFA Inline Chemical Heater Descriptions:



Product Name: 2KW 3.5KW Ultrapure PFA Inline Chemical Heater

2KW 3.5KW Ultrapure PFA Inline Chemical Heater are ideal for heating deionized water, acids, and less aggressive process chemistries use in high-purity processes of semiconductor, solar, MEMS manufacturing, and other industries using high-purity fluids.
These heaters are designed for recirculation and point-of-use fluid heating applications.
Their small footprints allow them to easily integrate into current systems.
Available in 3-18 kW and various voltages


Features & Benefits

Ultrapure design with PVDF/PFA wetted surfaces
Fast response with low watt density
No nitrogen purge required, reducing operating costs
Compact design of 10-30-in. heights, 4-6-in. diameters
Flexible designs with many options, safety features, voltages, and power outputs



Summary of parameters:

Ultrapure water heater value
voltage 110~415V 1p/3P
Power 6~18KW
Maximum pressure 0.4MPa
Minimum pressure 0.1MPa
Maximum flow 30L/min
Maximum operating temperature 120℃

Notes

1) This product must be installed vertically
2) The use process must be grounded
3) Water must be passed before heating
4) Product size and technical parameters can be customized according to customer needs


Applications

Semiconductor Wet Processes
Sterilization/Cleaning
Solar/Photovoltaic Wafer Cleaning



FAQ
Q: Are electric immersion heaters safe?
A: Is it safe to use an immersion heater?
Yes, it is, provided you buy a good product and use it appropriately.
You can even use it to boil drinking water and coffee.
Electrocution, burns, and short circuits may occur if you do not use the correct immersion water heater or wrongly utilize it.
Q: Where is Surplus located?
A: Our office located in HongKong,Dongguan and Shantou City.Our factory located in Shenzhen.

Q: Can I buy direct?
A: Yes,you can buy from Surplus Directly.

Q: Do you manufacture your products in house?
A: Most of our products are manufactured in-house at our factory.Some accessory items are not.

Q: Can I get the riser on my L-shaped aquaculture heater longer/shorter?
A: Yes.There is no price difference for making a heater with a middle riser,but there maybe a cost adder for a longer riser.

Q: What Third Party Approvals do your products carry(CE?)
A: Almost all of our products are CE compliant.

Q: How late can you ship?
A: Normally 7 days after comfirmed the order.

PACKING & SHIPPING
In our company,various packing methods are adopted according to different product features,such as carton boxes,wooden case etc.For electroplating plant equipment ,we can discuss it together and choose the most suitable one.

As for shipment,different ways have their own advantage and disadvantage:
By sea: the cheapest,suitable for large amounts,but take more time
By Air: faster, more convenient, expensive
By Express: more flexiable, door to door, expensive

RELATED SPECIES

  2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 0 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 1 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 2 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 3
METAL IMMERSION HEATER PTC IMMERSION HEATER QUARTZ IMMERSION HEATER
2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 4 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 5 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 6
METAL HEAT EXCHANGERS (PFA) HEAT EXCHANGERS ANODE BASKET
2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 7 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 8 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 9
PP TANKS PP BARRELS PP BAG FILTERS


OUR FACTORY

2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 10 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 11 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 12
ENGINEER OFFICE TOOLING DEPARTMENT MACHING 1
2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 13 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 14 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 15
MACHING 2 MACHING 3 MACHING 4
2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 16 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 17 2KW 3.5KW Ultrapure PFA Inline Chemical Heater For Semiconductor Wet Processes 18


Company Advantage

For more than ten years, our company has specialized in the research and development and production of PCB and FPC electroplating equipment, electric heaters, cold heat exchangers, and coating on the surface of electroplating equipment. We have collected advanced technologies and processes at home and abroad for many years. With the practice and experience in the PCB industry, the quality, stability and reliability of the products are among the world's leading positions. Our company has passed ISO9001: 2008 quality management system certification and CQC: CE certification, is in line with the world, implements scientific management, and implements international quality standards.
