PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor

Basic Information
Place of Origin: China
Brand Name: surplus
Certification: ISO9001
Model Number: T059
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 7-15 working days
Payment Terms: T/T, Western Union
Supply Ability: 100 pcs per month
Detail Information
Product Name: PFA Frame Heater,400V 3P 10KW Included PT-100 Temperature Sensor Power Source: Electric
Voltage: 120-600V Certification: ISO9001 CE
Warranty: 1 Year Tube Material: PTFE/PFA
Application: Semiconductor,pharmaceutical,and Biomedical Industries Dimension: Customized
Use In Tank Material Of: PVDF,PFA,or Quartz
High Light:

400V PFA Frame heater

,

10KW PFA Frame heater

,

Included PFA Frame heater


Product Description

PFA Frame Heater,400V 3P 10KW Included PT-100 Temperature Sensor

Surplus Industrial Technology Limited Frame Heater...

PFA Frame Heater,400V 3P 10KW Included PT-100 Temperature Sensor
Having over 2,000 different designs with size, kW rating, and voltage, We provides the widest range of immersion heaters to meet your needs. We provide the best fit to your process by offering a variety of grid heaters, frame heaters, and fence heaters.

PFA Frame Heater

Product Models

A single layer of PFA jacketed heating coils affixed to a PTFE grid. Height is ~3/4 inches.


Frame Heaters

Multiple layers of PFA jacketed heating coils affixed to a PTFE frame to keep the center of a tank empty and to run the heater around the inner side of the tank.
Height is adjustable on number of coil layers. Height is ~1-1/2 inches.


Fence Heaters

Multiple layers of PFA jacketed heating coils affixed to a PTFE fence to keep the center of a tank empty and to run the heater around the inner side of the tank.
Height is adjustable on number of coil layers.


PFA Frame Heater Operating Instructions

Verify heater has the following safeties and are properly interlocked to prevent unsafe heater conditions.
• Hi-Limit • Liquid Level
• Thermal Cut-Off
• Process Fluid Over Temperature



Heater

PFA Frame Heater

Wetted Surfaces

PFA

Sizes

1.0kW to 36kW (Dependent on Customer Voltage)

Voltages

120VAC to 480VAC 1 or 3ph (Dependent on Wattage)

Temperature

200°C (392°F)

Temperature Accuracy

±0.1°C (Contingent on Customer's Facilitation)

Efficiency

>99 %


FAQ

Q: What are the available options?
A:  • Perforated top and bottom floor grid
      • Thermal cut-off sensor for 72-240°C
      • PFA tubing on lead wires (10-ft)
      • Additional lead wires (15-ft or 20-ft)
      • Over-temperature thermocouple
      • Process thermocouple
      • Platinum or embedded ground wire

Q: Where is Surplus located?
A: Our office located in HongKong,Dongguan and Shantou City.Our factory located in Shenzhen.

Q: Can I buy direct?
A: Yes,you can buy from Surplus Directly.

Q: Do you manufacture your products in house?
A: Most of our products are manufactured in-house at our factory.Some accessory items are not.

Q: Can I get the riser on my L-shaped aquaculture heater longer/shorter?
A: Yes.There is no price difference for making a heater with a middle riser,but there maybe a cost adder for a longer riser.

Q: What Third Party Approvals do your products carry(CE?)
A: Almost all of our products are CE compliant.

Q: How late can you ship?
A: Normally 7 days after comfirmed the order.

PACKING & SHIPPING
In our company,various packing methods are adopted according to different product features,such as carton boxes,wooden case etc.For electroplating plant equipment ,we can discuss it together and choose the most suitable one.

As for shipment,different ways have their own advantage and disadvantage:
By sea: the cheapest,suitable for large amounts,but take more time
By Air: faster, more convenient, expensive
By Express: more flexiable, door to door, expensive

RELATED SPECIES

  PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 0 PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 1PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 2PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 3
METAL IMMERSION HEATERPTC IMMERSION HEATERQUARTZ IMMERSION HEATER
PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 4PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 5PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 6
METAL HEAT EXCHANGERS(PFA) HEAT EXCHANGERSANODE BASKET
PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 7PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 8PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 9
PP TANKSPP BARRELSPP BAG FILTERS


OUR FACTORY

PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 10PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 11PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 12
ENGINEER OFFICETOOLING DEPARTMENTMACHING 1
PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 13PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 14PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 15
MACHING 2MACHING 3MACHING 4
PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 16PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 17PFA Frame Heater 400V 3P 10KW Included PT-100 Temperature Sensor 18


Company Advantage

For more than ten years, our company has specialized in the research and development and production of PCB and FPC electroplating equipment, electric heaters, cold heat exchangers, and coating on the surface of electroplating equipment. We have collected advanced technologies and processes at home and abroad for many years. With the practice and experience in the PCB industry, the quality, stability and reliability of the products are among the world's leading positions. Our company has passed ISO9001: 2008 quality management system certification and CQC: CE certification, is in line with the world, implements scientific management, and implements international quality standards.
