Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible

Basic Information
Place of Origin: China
Brand Name: surplus
Certification: ISO9001
Model Number: T001
Minimum Order Quantity: 1pcs
Price: according the dimension
Packaging Details: wooden case
Delivery Time: 7-15 working days
Payment Terms: T/T, Western Union
Supply Ability: 100 pcs per month
Detail Information
Power Source: Electric Dimension(L*W*H): Custom Size
Voltage: 120-600V Certification: ISO9001 CE
Product Name: Industrial Process PTFE Immersion Heaters & Flexible Heaters For Wafer Cleaning Equipment Warranty: 1 Year
Material: Fluoropolymer (PTFE) Application: Industry Heating Process
High Light:

High efficiency PTFE Immersion Heater

,

130 Celsius PTFE Immersion Heater

,

130 Celsius electric immersion water heater


Product Description

Industrial Process PTFE Immersion Heaters & Flexible Heaters For Wafer cleaning equipment



1.  Fluoropolymer Sleeve Heating Element Quality resistance element is sleeved in braided material for even coil separation. The entire element is given an outer sleeving of pretested and pre-extruded fluoropolymer tubing. THIS IS NOT A COATED PRODUCT.

Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 0

2. Over-temperature Thermocouple The over-temperature cutoff device protects the integrity of the fluoropolymer heater. If an opera- tor should leave the heater on while draining or aspirating a tank, when used in conjunction with a temperature control device, it will automatically shut off the heater when it is exposed to air.



3. Designed for the most demanding chemical applications and to provide years of trouble-free performance.

FEATURES

1. Constructed with our exclusive elements for extended service life.

2. High efficiency in a compact design, and an excellent alternative for replacing strip heaters on quartz tanks.

3. TFP for bottom heater applications and inside tank wall requirements.

All wetted parts are fluoropolymer and compatible with virtually any chemistry for unlimited process options.

(Not to be used with flammable solutions.)

4. Low watt density design promotes process temperature uniformity.

SPECIFICATIONS

1. From 2,000 - 36,000 watts

2. 120 to 600 volts, single or three phase

3. Up to 10 watts per square inch (1.5w/cm2)

4. Up to 130º Celsius (266° F). For higher temperatures, see Options section.

5. OPTIONS AVAILABLE (CONSULT FACTORY)

   .030 inch (0.76mm) thick sheath available for applications above 130°C (266° F) or for use with certain chemistries such as nitride etch or HF

   PID temperature control module

   Custom configurations and lengths

   Element gas purge flow regulator panel

   Bolt down feature



FAQ
Q: Where is Surplus located?
A: Our office located in HongKong,Dongguan and Shantou City.Our factory located in Shenzhen.

Q: Can I buy direct?
A: Yes,you can buy from Surplus Directly.

Q: Do you manufacture your products in house?
A: Most of our products are manufactured in-house at our factory.Some accessory items are not.

Q: Can I get the riser on my L-shaped aquaculture heater longer/shorter?
A: Yes.There is no price difference for making a heater with a middle riser,but there maybe a cost adder for a longer riser.

Q: What Third Party Approvals do your products carry(CE?)
A: Almost all of our products are CE compliant.

Q: How late can you ship?
A: Normally 7 days after comfirmed the order.

PACKING & SHIPPING
In our company,various packing methods are adopted according to different product features,such as carton boxes,wooden case etc.For electroplating plant equipment ,we can discuss it together and choose the most suitable one.

As for shipment,different ways have their own advantage and disadvantage:
By sea: the cheapest,suitable for large amounts,but take more time
By Air: faster, more convenient, expensive
By Express: more flexiable, door to door, expensive

RELATED SPECIES

Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 1 Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 2 Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 3 Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 4
METAL IMMERSION HEATER PTC IMMERSION HEATER QUARTZ IMMERSION HEATER
Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 5 Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 6 Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 7
METAL HEAT EXCHANGERS (PFA) HEAT EXCHANGERS ANODE BASKET
Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 8 Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 9 Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 10
PP TANKS PP BARRELS PP BAG FILTERS


OUR FACTORY

Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 11 Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 12 Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 13
ENGINEER OFFICE TOOLING DEPARTMENT MACHING 1
Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 14 Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 15 Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 16
MACHING 2 MACHING 3 MACHING 4
Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 17 Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 18 Industrial High Efficiency 130 Celsius PTFE Immersion Heater Flexible 19


Company Advantage

For more than ten years, our company has specialized in the research and development and production of PCB and FPC electroplating equipment, electric heaters, cold heat exchangers, and coating on the surface of electroplating equipment. We have collected advanced technologies and processes at home and abroad for many years. With the practice and experience in the PCB industry, the quality, stability and reliability of the products are among the world's leading positions. Our company has passed ISO9001: 2008 quality management system certification and CQC: CE certification, is in line with the world, implements scientific management, and implements international quality standards.
