Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution

Certification
China Surplus Industrial Technology Limited certification
Customer Reviews
The heaters and the rectifier working great!

—— David

I'm Online Chat Now

Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution

Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution
Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution
Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution

Large Image :  Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution

Product Details:
Place of Origin: China
Brand Name: surplus
Certification: ISO9001
Model Number: T069
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 7-15 working days
Payment Terms: T/T, Western Union
Supply Ability: 100 pcs per month

Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution

Description
Product Name: Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution Power Source: Electric
Voltage: 120-600V Certification: ISO9001 CE
Warranty: 1 Year Tube Material: PTFE/PFA
Application: Semiconductor,pharmaceutical,and Biomedical Industries Dimension: Customized
High Light:

2 Phase PTFE Immersion Heater

,

3000W PTFE Immersion Heater

,

PTFE Immersion Heater

Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution

Surplus Industrial Technology Limited Frame Heater...

PFA Frame Heater,400V 3P 10KW Included PT-100 Temperature Senso

Frame Heaters

T10 series Power(W) Voltage(V) Dimension (MM)
Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 0 4500 380 830*185*40
6000 380 830*185*40
9000 380 830*185*40
12000 380 850*300*40
15000 380 850*350*40
24000 380 700*700*40




Ultrapure Design

• All-PFA wetted surfaces
• Patented heating coil
• Effective solution for harsh chemicals

Heating Element

Heater coils are specialized heating elements with PFA wetted surfaces for ultrapure applications.

They are ideal for harsh chemicals to up to 200°C.



Heater

PFA Frame Heater

Wetted Surfaces

PFA

Sizes

1.0kW to 36kW (Dependent on Customer Voltage)

Voltages

120VAC to 480VAC 1 or 3ph (Dependent on Wattage)

Temperature

200°C (392°F)

Temperature Accuracy

±0.1°C (Contingent on Customer's Facilitation)

Efficiency

>99 %



How To Select A Chemical Solution Heater
For corrosive solutions heating, the best of heater will depend on:

  • pH value- either highly acidic or alkaline
  • Specific heat and density of the chemical solution
  • Sheath and plating tank material
  • Corrosion resistive property of the materials

Dont hesitate to contact us, we have been helping manufacturers heat dangerous chemicals for almost 50 years.
Custom designed L shaped or bottom immersion heaters made of Teflon are also available.

FAQ

Q: Where is Surplus located?
A: Our office located in HongKong,Dongguan and Shantou City.Our factory located in Shenzhen.
     Our branch :Yiwu Yingxi Trading Company

Q: Can I buy direct?
A: Yes,you can buy from Surplus Directly.

Q: Do you manufacture your products in house?
A: Most of our products are manufactured in-house at our factory.Some accessory items are not.

Q: Can I get the riser on my L-shaped aquaculture heater longer/shorter?
A: Yes.There is no price difference for making a heater with a middle riser,but there maybe a cost adder for a longer riser.

Q: What Third Party Approvals do your products carry(CE?)
A: Almost all of our products are CE compliant.

Q: How late can you ship?
A: Normally 7 days after comfirmed the order.

PACKING & SHIPPING
In our company,various packing methods are adopted according to different product features,such as carton boxes,wooden case etc.For electroplating plant equipment ,we can discuss it together and choose the most suitable one.

As for shipment,different ways have their own advantage and disadvantage:
By sea: the cheapest,suitable for large amounts,but take more time
By Air: faster, more convenient, expensive
By Express: more flexiable, door to door, expensive

RELATED SPECIES

  Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 1 Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 2 Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 3 Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 4
METAL IMMERSION HEATER PTC IMMERSION HEATER QUARTZ IMMERSION HEATER
Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 5 Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 6 Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 7
METAL HEAT EXCHANGERS (PFA) HEAT EXCHANGERS ANODE BASKET
Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 8 Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 9 Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 10
PP TANKS PP BARRELS PP BAG FILTERS


OUR FACTORY

Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 11 Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 12 Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 13
ENGINEER OFFICE TOOLING DEPARTMENT MACHING 1
Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 14 Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 15 Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 16
MACHING 2 MACHING 3 MACHING 4
Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 17 Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 18 Frame Heater 2 Phase 3000W 400V PTFE Immersion Heater For Chemical Solution 19


Company Advantage

For more than ten years, our company has specialized in the research and development and production of PCB and FPC electroplating equipment, electric heaters, cold heat exchangers, and coating on the surface of electroplating equipment. We have collected advanced technologies and processes at home and abroad for many years. With the practice and experience in the PCB industry, the quality, stability and reliability of the products are among the world's leading positions. Our company has passed ISO9001: 2008 quality management system certification and CQC: CE certification, is in line with the world, implements scientific management, and implements international quality standards.
