400V 1P 3KW PFA Frame Heater PFA Immersion Tank Heaters

Basic Information
Place of Origin: China
Brand Name: surplus
Certification: ISO9001
Model Number: T065
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 7-15 working days
Payment Terms: T/T, Western Union
Supply Ability: 100 pcs per month
Detail Information
Product Name: 400V 1P 3KW PFA Frame Heater PFA Immersion Tank Heaters Power Source: Electric
Voltage: 120-600V Certification: ISO9001 CE
Warranty: 1 Year Tube Material: PTFE/PFA
Application: Semiconductor,pharmaceutical,and Biomedical Industries Dimension: Customized
Use In Tank Material Of: PVDF,PFA,or Quartz
High Light:

3KW PFA Frame Heater

,

Immersion Tank PFA Frame Heater

,

400V PFA Frame Heater


Product Description

400V 1P 3KW PFA Frame Heater PFA Immersion Tank Heaters

Surplus Industrial Technology Limited Frame Heater...

PFA Frame Heater,400V 3P 10KW Included PT-100 Temperature Sensor
Having over 2,000 different designs with size, kW rating, and voltage, We provides the widest range of immersion heaters to meet your needs. We provide the best fit to your process by offering a variety of grid heaters, frame heaters, and fence heaters.



PFA TANK HEATERS ARE DESIGNED TO HEAT FLUID IN CONSTANT-TEMPERATURE BATHS, acid etch tanks and other liquid heating applications in the semiconductor, solar cell, pharmaceutical, and biomedical industries that require the direct application of uniform heating.



These heaters feature an all-PFA wetted surface and are designed to easily integrate into PVDF, PFA, and quartz process tanks (please contact us with inquiries about other tank materials).



The immersion heaters are available in a variety of customizable designs.

PFA Frame Heate

Frame Heaters

Ultrapure Design

• All-PFA wetted surfaces
• Patented heating coil
• Effective solution for harsh chemicals

Heating Element

Heater coils are specialized heating elements with PFA wetted surfaces for ultrapure applications.

They are ideal for harsh chemicals to up to 200°C.



Heater

PFA Frame Heater

Wetted Surfaces

PFA

Sizes

1.0kW to 36kW (Dependent on Customer Voltage)

Voltages

120VAC to 480VAC 1 or 3ph (Dependent on Wattage)

Temperature

200°C (392°F)

Temperature Accuracy

±0.1°C (Contingent on Customer's Facilitation)

Efficiency

>99 %



How To Select A Chemical Solution Heater
For corrosive solutions heating, the best of heater will depend on:

  • pH value- either highly acidic or alkaline
  • Specific heat and density of the chemical solution
  • Sheath and plating tank material
  • Corrosion resistive property of the materials

Dont hesitate to contact us, we have been helping manufacturers heat dangerous chemicals for almost 50 years.

Custom designed L shaped or bottom immersion heaters made of Teflon are also available.


FAQ

Q: What are the available options?
A:  • Perforated top and bottom floor grid
      • Thermal cut-off sensor for 72-240°C
      • PFA tubing on lead wires (10-ft)
      • Additional lead wires (15-ft or 20-ft)
      • Over-temperature thermocouple
      • Process thermocouple
      • Platinum or embedded ground wire

Q: Where is Surplus located?
A: Our office located in HongKong,Dongguan and Shantou City.Our factory located in Shenzhen.

Q: Can I buy direct?
A: Yes,you can buy from Surplus Directly.

Q: Do you manufacture your products in house?
A: Most of our products are manufactured in-house at our factory.Some accessory items are not.

Q: Can I get the riser on my L-shaped aquaculture heater longer/shorter?
A: Yes.There is no price difference for making a heater with a middle riser,but there maybe a cost adder for a longer riser.

Q: What Third Party Approvals do your products carry(CE?)
A: Almost all of our products are CE compliant.

Q: How late can you ship?
A: Normally 7 days after comfirmed the order.

PACKING & SHIPPING
In our company,various packing methods are adopted according to different product features,such as carton boxes,wooden case etc.For electroplating plant equipment ,we can discuss it together and choose the most suitable one.

As for shipment,different ways have their own advantage and disadvantage:
By sea: the cheapest,suitable for large amounts,but take more time
By Air: faster, more convenient, expensive
By Express: more flexiable, door to door, expensive
