Non Dry Burning 6000W 35mm PTC Immersion Heater Over The Side

Basic Information
Place of Origin: China
Brand Name: surplus
Certification: ISO9001,CE
Model Number: PTC001
Minimum Order Quantity: 1pcs
Price: according the specification
Packaging Details: wooden case
Delivery Time: 5-7working days
Payment Terms: T/T, Western Union
Supply Ability: 200pcs per month
Detail Information
Power Source: Electric Shape: Straight
Power(W): Customizable Voltage: 120V-600V
Material: Stainless Steel,Titanium Application: Industry Heating Process
Usage: Immersion Heater Water Tube Diameter: 35mm, 45mm, 50mm
Heating Element: Semiconductor Heating Element Warranty: 1 Year
High Light:

6000W PTC Immersion Heater

,

35mm PTC Immersion Heater

,

35mm industrial water heating systems


Product Description

Non-dry Burning PTC Over The Side Industrial Electric Immersion Heater​

PTC Electric Immersion Heater



LONG ELEMENT LIFE:
• Patented PTC heater element lasts longer than conventional heaters.
• Will not burn out if run in air.
• Will not burn out due to scale or sludge buildup.



SAFE DESIGN:
• Heater self limits its maximum operating temperature to 482F (250 degree C). This is lower than the ignition point of most plastics.
• Will not melt tanks when a 1/2" (12mm) minimum distance is maintained.
• Overtemperature protection devices are not required.
• Safety is built-in, not added on.
• Metal-grounded construction (earth ground).
• Non-floating construction.



SIZES: 1,000 watts (1kW) to 6,000 watts (6kW).



VOLTAGES:
Three voltage ranges available: 120 volt, 200-240 volt, and 380-480 volt.
Heater is available in single or three phase power.



CORROSION RESISTANT HEADS: Vapor resistant, flame retardant polypropylene terminal enclosures each with 3-foot (.9m) flexible PVC liquid tight conduits.



OUTSTANDING PERFORMANCE:
• Watt densities of 26 watts per square inch (4 watts/cm2) ensure long service life.
• Auto-stabilizing solid state element prevents hot spots and ensures uniform heating.
• Heater derates itself in highly viscous and high temperature solutions. Consult factory for sizing assistance.



CHEMICALLY RESISTANT:
For use in most aqueous alkaline, electroplating and rinse solutions. Check our Solution Guide or with your chemical supplier for recommended sheath material. Available in:
• 304 stainless steel
• 316 stainless steel
• Titanium



CERTIFICATIONS: ISO9001 and CE

Tube Diameter: 50mm(2-inch) standard


We have custom built heaters and can make any Watts,voltages with the size according to customers’ requirement

OPTIONS :(consult Our FACTORY for any installation)



FAQ
Q: Where is Surplus located?
A: Our office located in HongKong,Dongguan and Shantou City.Our factory located in Shenzhen.


Q: Can I buy direct?
A: Yes,you can buy from Surplus Directly.


Q: Do you manufacture your products in house?
A: Most of our products are manufactured in-house at our factory.Some accessory items are not.


Q: Can I get the riser on my L-shaped aquaculture heater longer/shorter?
A: Yes.There is no price difference for making a heater with a middle riser,but there maybe a cost adder for a longer riser.


Q: What Third Party Approvals do your products carry(CE?)
A: Almost all of our products are CE compliant.


Q: How late can you ship?
A: Normally 7 days after comfirmed the order.


PACKING & SHIPPING
In our company,various packing methods are adopted according to different product features,such as carton boxes,wooden case etc.For electroplating plant equipment ,we can discuss it together and choose the most suitable one.
As for shipment,different ways have their own advantage and disadvantage:
By sea: the cheapest,suitable for large amounts,but take more time
By Air: faster, more convenient, expensive
By Express: more flexiable, door to door, expensive


RELATED SPECIES

Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 1 Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 2 Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 3
PTFE IMMERSION HEATER PTC IMMERSION HEATER QUARTZ IMMERSION HEATER
Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 4 Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 5 Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 6
METAL HEAT EXCHANGERS (PFA) HEAT EXCHANGERS ANODE BASKET
Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 7 Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 8 Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 9
PP TANKS PP BARRELS PP BAG FILTERS


OUR FACTORY

Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 10 Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 11 Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 12
ENGINEER OFFICE TOOLING DEPARTMENT MACHING 1
Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 13 Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 14 Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 15
MACHING 2 MACHING 3 MACHING 4
Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 16 Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 17 Z-Shaped Over The Side Small Tube Stainless Steel Heater For Water Heating 18


Company Advantage
For more than ten years, our company has specialized in the research and development and production of PCB and FPC electroplating equipment, electric heaters, cold heat exchangers, and coating on the surface of electroplating equipment. We have collected advanced technologies and processes at home and abroad for many years. With the practice and experience in the PCB industry, the quality, stability and reliability of the products are among the world's leading positions. Our company has passed ISO9001: 2008 quality management system certification and CQC: CE certification, is in line with the world, implements scientific management, and implements international quality standards.
